Milwaukee 4115 Coring & Drill Press Stand Parts

Milwaukee 4115 Parts

STAND SM BASE

Download Schematic

Time to buy a new tool?

Milwaukee 4115

Diamond Coring Small...

$535.99

Tool Diagram (Click image to Zoom in) View larger Image

ToolspartsPro

Fig.	Part #	Part Name	Price
1	06-55-1525	"1/4""-20 Hex Nut"	$0.86
2	06-75-3050	1/4-20x3/4 Skt. Hd. Screw	$0.86
3	06-75-3920	5/16-18 Socket Hd. Screw	$3.83
4	06-75-0970	"1/2-13 x 2-3/4"" Hex Hd. Screw"	$1.24
5	06-75-5840	3/8-16 Socket Hd. Cap Screw	$3.34
6	06-75-5845	5/8-11 Hex Hd. Cap Screw	$2.24
7	06-83-5150	"5/8-11 x 4-1/2"" Level Screw"	$1.80
8	06-83-6010	"1/4-20 x 1-1/2"" Set Screw"	$1.80
9	06-83-6020	"1/4-20 x 1"" Set Screw"	$3.17
10	06-97-4110	"5/16"" Split Ring Lock Washer"	$0.86
13	06-97-4400	"5/8"" Split Ring Lockwasher"	$1.08
14	12-99-1310	Nameplate Blank	$6.58
15	28-06-1110	Small Base	$224.27
16	28-23-3415	Carriage	$221.55
17	36-66-4620	Pinion Shaft	$37.28
18	06-75-2950	1/4-20x1/2 Skt. Hd. Cap Screw	$0.86
19	42-78-0050	Column	$136.24
22	43-96-0200	"3/8 x 3/8 x 3"" Key"	$5.54
23	43-96-0210	"3/8 x 3/8 x 5"" Key"	$6.25
24	43-98-0050	Plastic Knob	$2.35
25	43-98-0525	Carriage Screw	$4.05
26	44-10-0365	Bar Handle	$7.19
27	44-34-0190	Motor Mount	$41.46
28	44-52-0605	Wear Pad	$13.02
29	44-52-0665	Gib	$9.66
30	44-52-0675	Wear Pad	$13.07
31	44-80-0175	Rack	$89.35
32	45-04-0535	Jack Screw Assembly	$26.11
33	45-58-0280	Switch Box Mounting Stud	$8.56
34	45-88-7460	Washer	$1.46
35	45-88-8675	Shaft Washer	$1.30
36	45-94-0135	Wheel	$12.36
37	06-97-4050	"1/4"" Split Ring Lock Washer"	$0.86
38	06-75-3090	"1/4-20 x 7/8"" Socket Hd. Screw"	$0.86
100	49-96-0060	"1/8"" Socket Wrench"	$0.86
101	49-96-0080	"3/16"" Hex Key (Not Shown)"	$1.03
103	49-96-0120	"5/16"" Allen Wrench (Not Shown)"	$2.95
