Makita DP4000 Cordless Drill Parts

Makita DP4000 Cordless Drill Parts Image

Makita DP4000 Parts

Brand Logo Download Tool Parts PDF Download Schematic

Time to buy a new tool?
Makita DP4000
1/2 Inch Variable-Sp...
$171.99
Free Shipping
Tool Diagram    (Click image to Zoom in) View larger Image
Makita DP4000 Cordless Drill Parts Breakdown Diagram
ToolspartsPro

Fig.Part #ImgPart NamePriceQty.
2 285807-7 BEARING RETAINER 22-36, 5008FA $3.06
3 324039-2 SPINDLE, DP4002 $14.61
4 254202-2 KEY 4, 9924DB $1.26
5 211206-7 B. BEARING 6202LLB, NHP1310 $10.98
6 961055-9 RETAINING RING S-15, 5007F $1.19
7 317401-8 GRIP BASE, DP4000 $11.97
8 266261-4 BOLT M8X130, DP3003 $3.28
9 317397-3 GEAR HOUSING, DP4002 $19.34
10 226529-0 HEICAL GEAR 26, DP4002 $9.77
11 267143-3 FLAT WASHER 11, BTD060Z $1.63
12 961051-7 RETAINING RING S-11, DP4000 $1.48
13 152639-6 GEAR HOUSING COVER CPL., DP4002 $23.41
14 253804-1 F. WASHER 6, 6012HDW $1.34
15 226136-9 GEAR COMPLETE, DP4000 $18.02
16 253133-2 F. WASHER 7, DP4000 $1.34
17 211021-9 BALL BEARING 607LLB, LS1013 $8.78
18 266050-7 P.T. SCREW 4X30, 4304 $1.19
19 266069-6 T. SCREW FLANGE PT4X45 HR2410 $1.74
20 152521-9 GRIP 36 CPL., DP4002 $4.49
21 211012-0 BALL BEARING 606ZZ, HR2410 $15.27
22 226137-7 GEAR COMPLETE, DP4000 $20.77
23 253804-1 F. WASHER 6, 6012HDW $1.34
24 421479-6 RUBBER RING 19, JN1601 $4.49
25 211021-9 BALL BEARING 607LLB, LS1013 $8.78
26 681636-0 INSULATION WASHER, GA4030 $3.72
27 517356-9 ARMATURE ASSY 115V, DP4002 $68.40
28 241873-4 FAN 55, 6922NB $7.02
29 211031-6 BALL BEARING 608LLB, 9227C $10.98
30 417356-8 BAFFLE PLATE, DP4002 $1.52
31 633466-5 FIELD 115V, DP4002 $17.25
32 417625-7 HOOK, 6827 $2.84
33 183270-7 MOTOR HOUSING SET, DP4000,DP4002 $19.78
35 643951-0 BRUSH HOLDER, 6824 $3.06
36 152641-9 HANDLE COVER CPL., DP3003 $21.10
37 265999-8 TAPPING SCREW M4X25, HM1800 $1.19
38 265999-8 TAPPING SCREW M4X25, HM1800 $1.19
39 651991-4 SWITCH, DP4002 $37.53
40 265995-6 TAPPING SCREW 4X18, BO4556K $0.86
41 687063-9 STRAIN RELIEF, 4323K $1.26
42 664064-4 CORD (2X18X8 SJ), BO4556 $16.04
42 EC182 This item will be shipped Free Power Tools Replacement Electical Cords (SJO) 18... $10.19
43 682559-5 CORD GUARD 8, 6824 $2.51
43 Boot-C This item will be shipped Free Strain Relief fits 18/2 AWG only $4.19
44 417358-4 SLIDE LEVER, DP3003 $1.26
45 643948-9 BRUSH HOLDER, 6823 $2.84
48 266060-4 TAPPING SCREW 4X65, HP2030 $3.61
49 410102-8 KEY HOLDER, 6013BR $1.26
50 134903-7 GRIP 36 ASS'Y, DP3003 $11.97
401 763434-5 CHUCK KEY 10, 6302H,6303H $6.00
