DeWalt DW297 Electric Impact Wrench Parts

DeWalt DW297 Electric Impact Wrench Parts Image

DeWalt DW297 Parts

Brand Logo Download Tool Parts PDF Download Schematic

Time to buy a new tool?
DeWalt DW297
3/4 Inch (19mm) Heav...
$515.95
Tool Diagram    (Click image to Zoom in) View larger Image
DeWalt DW297 Electric Impact Wrench Parts Breakdown Diagram
ToolspartsPro

Fig.Part #ImgPart NamePriceQty.
1 5140003-01 BUMPER $54.06
2 5140003-02 O-RING $5.67
3 5140003-03 HAMMER CASE ASSEMBLY $212.62
4 5140003-04 PLUNGER $25.80
5 5140003-05 SPRING $3.01
6 5140003-06 ROLL PIN $3.81
7 5140003-07 ANVIL $155.49
8 5140003-08 STEEL BALL $3.01
9 5140003-09 HAMMER $155.49
10 5140003-10 SPRING $27.62
11 5140003-11 SPRING SEAT $50.68
12 5140003-12 STEEL BALL $3.01
13 5140003-13 SHAFT $11.24
14 5140003-14 SPINDLE $204.52
15 5140003-15 IDLER GEAR $59.10
16 5140003-16 CLIP $3.01
17 5140003-17 RING GEAR $50.68
18 5140003-18 BALL BEARING $48.24
19 5140003-19 O-RING $5.67
20 5140003-20 COVER $48.24
21 5140003-21 FELT SEAL $3.01
22 5140003-22 WASHER $3.01
23 5140003-23 BALL BEARING $16.79
24 5140003-24 ARMATURE & BRGS $245.32
25 5140003-25 FAN BAFFLE $5.67
26 5140003-26 FIELD $84.36
27 5140003-27 LEAD WIRE $9.36
28 607308-00 ID LABEL $3.01
29 5140003-29 COLLAR $7.54
30 5140003-30 HOUSING ASSEMBLY $147.24
31 656305-00 NAME PLATE $5.10
32 5140003-32 BOLT $1.95
33 5140003-33 SCREW $1.95
34 5140003-34 SCREW $1.95
35 5140003-35 CORD CLAMP $3.81
36 330005-01 PROTECTOR, CORD $4.63
36 Boot-C This item will be shipped Free Strain Relief fits 18/2 AWG only $4.19
37 330081-08 CORD, 16-2SJ $11.70
38 5140003-38 LEAD WIRE $9.36
39 5140003-39 TERMINAL $5.67
40 5140003-40 SCREW $1.95
41 5140003-41 COVER $5.67
42 5140003-42 BRUSH CAP $5.67
43 5140003-43 BRUSH $9.36
44 5140003-44 BRUSH HOLDER $13.08
45 5140003-45 SCREW $1.95
46 5140003-46 BALL BEARING $14.96
47 5140003-47 COVER $34.50
48 5140003-48 SCREW $1.95
49 5140003-49 SCREW $1.95
50 5140003-50 HANDLE COVER $25.90
51 5140003-51 SWITCH $50.68
52 5140003-52 ADAPTOR $5.67
53 5140003-53 SCREW $1.95
54 5140003-54 SWITCH BRACKET $9.36
55 5140003-55 TERMINAL BLOCK $14.96
56 5140003-00 SIDE HANDLE ASY $43.08
57 5140056-76 ROLL PIN $1.62
800 5140003-58 GREASE $37.95
